Boot Level Switch, CD

Boot Level Switch, CD

Product Details:

  • Max. Current 15 A Ampere (amp)
  • Temperature Range -20 - 60 Celsius (oC)
  • Rated Voltage 250 VAC Volt (V)
  • Protection Level IP53
  • Material NBR
  • Contact Resistance 15 A / 250 V AC Volt per ampere (V/A)
  • Max. Voltage 250 VAC Volt (V)
9,500 INR/Piece
X

Price And Quantity

  • 9,500 INR/Piece
  • 1 Piece

Product Specifications

  • 142 membrane diameter
  • IP53
  • 250 VAC Volt (V)
  • -20 to 60 Celsius (oC)
  • 0.48 Kilograms (kg)
  • 15 A Ampere (amp)
  • -20 - 60 Celsius (oC)
  • 15 A / 250 V AC Volt per ampere (V/A)
  • 250 VAC Volt (V)
  • Grey
  • NBR

Trade Information

  • All India

Product Description

Versatile membrane level indicator. Is to be used to control the maximum or minimum level of bulk solids in silos or vessels. These controllers consist of a switch actuated by a membrane and it is recommended for dusty and powdery, granulated and grainy bulk goods like dust, flour, grain, sand, plastic, etc. with an easy flow and a bulk density from 0.3 to 2.5 t/m3.


Function:
The membrane must to be exposed to the material. The movement of the switch is the result of the pressure exerted by the incoming bulk material against the membrane which forces the membrane to move backwards, reversing the position of the switch and the signal is used for example to control the transport system in the silo.

Tightening the regulation nut to reduce the sensitivity and increase the strain of the material to activate the microswitch. Clockwise insensitive.
The models are adjusted at their maximum sensitivity. It is necessary to ensure the proper pressure to the membrane that returns the membrane when there is no product covering it.
Mechanical connection:
Drill holes in the silo or vessel and mount the indicator using screws, rods, fasteners or nuts M6 making sure of the easy flow of the material and ensure that the product leaves the membrane without product on it.


Specification

CD Standard Ambient Temperature

-20 to +60 Deg C

Model Name/Number

CD

Brand

Filsa

Protection

IP53 / IP40 depending on the position of the cable gland

Maximum Voltage

250 V AC

Maximum Pressure

+0.5 bar

Housing Materials

Glass reinforced Polyester (Under request Aluminium)

CD with Aluminium Housing Weight

0.95 kg

CD with Aluminium Housing Ambient temperature

-25 to +80 Deg C

CD Standard Weight

0.48 kg
