Low Pressure Calibrator KAL100/200

Low Pressure Calibrator KAL100/200
X

Product Description

Special features

  • High level of accuracy and long-term stability through automatic zero-point calibration
  • Available for 4 measurement ranges
  • Simple menu navigation for unit conversion, setting calibration points and setting the measurement range
  • Menu navigation in German, English, Italian, French and Spanish
  • Generation of positive and negative differential pressures
  • Can be calibrated
  • Easy to operate and produce calibration curves via optional USB port and PC

Pressure calibration davice with integrated pressure generator for stationary and mobile applications

The KAL 100 can also be fitted with a USB port (optional). This allows testing protocols to be transferred simply to the PC. The instrument is available with a power supply and a measuring input for external test objects (optional). No additional power adapters or measuring instruments required for the test object. Available with lithium-ion rechargeable battery (optional). The instrument is available with a ISO factory calibration or DAkkS calibration certificate (optional).

Measurement ranges
0 .. 100 Pa, 0 .. 200 Pa, 0 .. 500 Pa
0 .. 1 kPa, 0 .. 2 kPa, 0 .. 5 kPa, 0 .. 10 kPa, 0 .. 20 kPa, 0 .. 50 kPa, 0 .. 100 kPa
± 100 Pa, ± 200 Pa, ± 500 Pa
± 1 kPa± 2 kPa, ± 5 kPa, ± 10 kPa, ± 20 kPa, ± 50 kPa, ± 100 kPa

Margin of error

± 0.2 % of max. value (Measurement ranges > 0 .. 200 Pa / ± 200 Pa) or
± 0.5 % of max. value (Measurement range ≤ 0 .. 200 Pa / ± 200 Pa)
(0.3 Pa margin of error for the reference)

Data interface
USB port (optional)

Input / power supply (test objects, optional)

0 .. 10 V or 0/4 .. 20 mA
Accuracy: 0.2 % of max. value
24 VDC / 100 mA
