Specification
Input |
Thermocouple, RTD, Exclusive hygrothermo sensor |
Indicating Accuracy |
+-Thermocouple: Within 0.2 % F.S |
|
+-RTD: Within 0.1% F.S |
|
+-Hygrothermo Sensor: Within 0.3 (% rH) |
Action Method |
Double Integration method |
Sampling Period |
0.4sec |
Power Supply |
3V DC size AA alkaline battery (2 pcs) |
Battery life |
200 hours in continuous duty without using backlight |
Dust-proof, drip-proof |
IP65 for the front panel |
|
Exclusive sensors |
Thermocouple (K)
Model |
Main targets |
Max. measuring |
PCE-701 |
For measuring |
0 to 400 |
PCE-702 |
For measuring a curved surface temperature |
0 to 400 |
PCE-704 |
For measuring |
0 to 400 |
PCE-706 |
For measuring |
0 to 400 |
PCE-707 |
For measuring |
0 to 400 |
PCE-707L |
For measuring |
0 to 400 |
PCE-H7 |
PCE-707 |
0 to 400 |
PCE-709 |
For measuring |
0 to 400 |
PCE-700M |
For measuring |
0 to 300 |
RTD (Pt100)
Model |
Main targets |
Max. measuring |
PCR-701 |
For measuring |
0 to 400 |
Hygrothermo transmitter
Model |
Measuring range |
THD-700-P |
Temperature: 0 to 50 |
Conversion plug
Model |
Remarks |
PCE-CP7 |
Temperature sensor for the DFT-600 |
![]() |
