Product Details:

Accuracy ±0.1 Brix
Temperature 0°C to 80°C
Equipment Type Inline Brix Transmitter
Mounting Type Inline, sanitary clamp
Test Range 0 to 50 Brix
Display Type Digital LED
Features Automatic temperature compensation, easy calibration, digital output, hygienic design, real-time monitoring
Share Your Product:

Get a Price/Quote

Request To Call Back Send Inquiry

DCM-20 Inline Brix Transmitter Product Specifications

Usage Process control, inline quality assurance
Measuring Range 0 to 50 Brix
Mounting Type Inline, sanitary clamp
Capacity Continuous inline measurement
Equipment Type Inline Brix Transmitter
Control Mode Automatic
Temperature 0°C to 80°C
Humidity 0 to 95% RH, non-condensing
Operating Voltage 24V DC
Power Supply 24V DC
Automation Grade Automatic
Features Automatic temperature compensation, easy calibration, digital output, hygienic design, real-time monitoring
Accuracy ±0.1 Brix
Application Sugar solution concentration measurement in food and beverage processing
Port Size 1 inch, Tri-clamp
Response Time <2 seconds
Machine Weight Approx. 1.2 kg
Resolution 0.01 Brix
Display Type Digital LED
Test Range 0 to 50 Brix
Interface Type 4-20mA, RS485 Modbus

Process Pressure 0 to 6 bar
Output Signal 4-20mA, RS485 digital communication
Sensor Type Optical refractometer
Cable Entry PG9
Wetted Material 316L Stainless Steel, food grade
Calibration User-programmable, one-touch digital calibration
Protection Class IP65
Compliance CE, RoHS

Product Description

Define liquid product interfaces in beverage and dairy filling lines
Achieve and ensure product quality in sugar dissolving, juice blending and jam vessels
Correlate membrane filtration efficiency in
protein separation in Reverse Osmosis and Ultra Filtration systems
Optimize steam feed in dairy evaporation processes

Accurate Inline Measurement for Sugar Solutions

Designed for real-time monitoring, the DCM-20 Inline Brix Transmitter provides continuous, precise measurements of sugar solution concentration (0-50 Brix) in processing lines. With automatic temperature compensation and rapid response time, it ensures reliable data for process control in food and beverage industries.

Hygienic and Durable Construction

The transmitter's wetted parts are crafted from food-grade 316L stainless steel, making it safe for contact with consumables. The sanitary tri-clamp mounting and IP65 protection grade further enhance its suitability for harsh, hygienic environments, guaranteeing longevity and ease of cleaning.

Simple Calibration and Real-Time Communication

Calibration is straightforward with user-programmable settings and one-touch digital calibration functionality. The device supports both 4-20mA analog output and RS485 digital communication, enabling seamless integration with automation systems and ensuring efficient process monitoring.

FAQ's of DCM-20 Inline Brix Transmitter:

Q: How does the DCM-20 Inline Brix Transmitter measure sugar concentration in process lines?

A: The DCM-20 utilizes an optical refractometer sensor to continuously and accurately measure the refractive index of sugar solutions, which correlates with Brix concentration. This permits real-time data for process control in food and beverage production.

Q: What are the benefits of using a food-grade 316L stainless steel construction?

A: The food-grade 316L stainless steel ensures hygienic and corrosion-resistant contact with process fluids, meeting industry standards for safety and durability in environments involving food and beverage processing.

Q: When should I calibrate the DCM-20 Brix transmitter?

A: It is recommended to calibrate the transmitter during initial installation, after maintenance, or if accuracy checks indicate deviation. The user-programmable, one-touch digital calibration makes routine calibration fast and uncomplicated.

Q: Where can the DCM-20 transmitter be installed in a processing plant?

A: The device is designed for inline and sanitary clamp mounting on process piping systems, making it ideal for installation within sugar solution lines in food and beverage manufacturing facilities.

Q: What output signals does the DCM-20 Inline Brix Transmitter provide for automation?

A: It supports standard 4-20mA analog output and RS485 digital communication (Modbus), facilitating easy integration with process control and data acquisition systems.

Q: How does the automatic temperature compensation improve measurement accuracy?

A: Automatic temperature compensation adjusts the Brix readings according to fluid temperature fluctuations, ensuring consistent measurement accuracy over a range from 0C to 80C.

Q: What is the primary usage of the DCM-20 Brix transmitter?

A: The transmitter is primarily used for continuous inline measurement and process control of sugar concentrations in food and beverage industries, enhancing quality assurance, automation, and real-time monitoring.
